HomePage Product LED High Bay Light E-Series High Bay

Up To 210 LM/W

Goldenlux E-Series LED High Bay Light is a Cost-Effective high-brightness led light source that combines high-performance 150 LM/W, 170 LM/W, 190 LM/W and 210 LM/W ultra-high-lumen output. The LED High Bay Light is suitable for a wide range of product application occasions and scenarios. It can be used in industrial facilities, warehouses, factories, workshops, and other large spaces that require high-quality lighting. The high bay light is ideal for applications that require high illuminance levels, such as in manufacturing processes, sports facilities, and exhibition halls.

A Variety Of Power Supply Options

Output wattage covers 100W-240W, Goldenlux try it best to become the leader of UFO High Bay Lighting design and make the efficiency of LED High Bay Lighting much more better. Simultaneously, we provided 0/1-10V or DALI2 dimming functions to allow customers to use smart lighting control for desired effect.Therefore, Goldenlux has comprehensive solutions for all kinds of application.
Up To

240W

Warranty

5 Years

Multi-Angle Display

Choose 120°,90° Or 60° Lens And Aluminum Reflectors Are Available As Accessories.

60°

90°

120°

Mounting Options

Eye-Bolt,Or Adjustable Bracket For Surface Mounting

Anti-Glare Reflector

Use this reflector to reduce glare from your 100-150-200 Wattage UFO LED High Bay Light and to create a traditional high bay look.The reflector installs around the fixture's lens and comes with 4 screws to secure it in place.

Motion Sensor Available

Applications like warehouses,distribution centers,production facilities and other industrial spaces with occupancy less than 50% and high ceilings(15–45 ft) are ideal environment for sensors.It helps save energy costs by delivering light only where you need it,when you need it.

Detail Parameters

Series E-Series LED High Bay Light
Power 100W,150W,200W,240W
Efficacy 150LM/W, 170LM/W, 190LM/W, 210LM/W
Input Voltage 120-277VAC, 50/60 Hz
Power Factor >0.9
Surge Protector 6KV Line-Line, 6KV Line-Earth
Control 1-10V, DALI2(Optional)
IP Rating IP65
IK Rating IK09
CCT 3000K/ 4000K/ 5000K/ 5700K/ 6500K
CRI CRI>70 Standard, CRI>80 Optional
Operating Temperature -30°C — +45°C
Beam Angle 60°, 90°, 120°
Mounting Option Loop Hanging, Bracket Mounting
Reflector Aluminum Reflector
Warranty 5 Years Warranty

Downloads

Test Report

Certification
